centos

vnc Server

  • sudo yum install tigervnc-server

  • sudo cp /lib/systemd/system/vncserver@.service /etc/systemd/system/vncserver@.service

  • sudo vim /etc/systemd/system/vncserver@.service

  • sudo systemctl daemon-reload

  • sudo systemctl enable vncserver@:1.service

  • sudo vncpasswd ~/.vnc/paawd

  • sudo firewall-cmd –state

  • sudo firewall-cmd –zone=public –add-port=5901/tcp –permanent

  • sudo firewall-cmd –zone=public –add-port=6001/tcp –permanent

  • sudo firewall-cmd –reload

  • sudo firewall-cmd –list-all

Centos 关闭selinux 和防火墙

  • vim /etc/selinux/config

  • 查看防火墙状态

    1
    firewall-cmd --state1

    停止firewall

    1
    systemctl stop firewalld.service1

    禁止firewall开机启动

    1
    systemctl disable firewalld.service

github-reinitialize

删除github上的commit历史记录

  1. 创建新的分支
    1
    2
    3
    git checkout  --orphan  new
    git add -A
    git commit -am "Re-init"
  2. 删除原master分支, 重命名master, 并提交
    git branch  -D master
    git branch -m master
    git push origin master  -f


现在你再去GitHub上去看提交分支的记录,会发现只有一次提交了

mongodb

MongoDB

  • 查看所有数据库

    show dbs

  • 创建或切换数据库

    use DB-Name

  • 删除当前数据库

    1
    db.dropDatabase()
  • 集合(表)

    • 创建

      1
      2
      3
      4
      5
      6
      db.createCollection(name, options)
      > use test
      switched to db test
      > db.createCollection("runoob")
      { "ok" : 1 }
      >
    • 查询

      使用 show collectionsshow tables 命令

      1
      2
      3
      > show collections
      runoob
      system.indexes
    • 在 MongoDB 中,你不需要创建集合。当你插入一些文档时,MongoDB 会自动创建集合。

      1
      2
      3
      4
      > db.mycol2.insert({"name" : "菜鸟教程"})
      > show collections
      mycol2
      ...
    • 删除集合

      1
      2
      3
      4
      5
      6
      7
      8
      > use runoob
      switched to db runoob
      > db.createCollection("runoob") # 先创建集合,类似数据库中的表
      > show tables
      runoob
      > db.runoob.drop()
      true
      > show tables

shell

移动光标

  • ctrl+b: 前移一个字符(backward)
  • ctrl+f: 后移一个字符(forward)
  • alt+b: 前移一个单词
  • alt+f: 后移一个单词
  • ctrl+a: 移到行首(a是首字母)
  • ctrl+e: 移到行尾(end)
  • ctrl+xx: 行首到当前光标替换

编辑命令

  • alt+.: 粘帖最后一次命令最后的参数(通常用于mkdir long-long-dir后, cd配合着alt+.
  • alt+d: 删除当前光标到临近右边单词开始(delete)
  • ctrl+u: 删除光标左边所有
  • ctrl+h: 删除光标前一个字符(相当于backspace)
  • ctrl+d: 删除光标后一个字符(相当于delete)
  • ctrl+w: 删除当前光标到临近左边单词结束(word)
  • ctrl+k: 删除光标右边所有
  • ctrl+l: 清屏
  • ctrl+shift+c: 复制(相当于鼠标左键拖拽)
  • ctrl+shift+v: 粘贴(相当于鼠标中键)

其它

  • ctrl+n: 下一条命令
  • ctrl+p: 上一条命令
  • alt+n: 下一条命令(例如输入ls, 然后按’alt+n’, 就会找到历史记录下的ls命令)
  • alt+p: 上一条命令(跟alt+n相似)
  • shift+PageUp: 向上翻页
  • shift+PageDown: 向下翻页
  • ctrl+r: 进入历史查找命令记录, 输入关键字。 多次按返回下一个匹配项

Vim

移动光标

  • b: 向前移动一个单词
  • w: 向后移动一个单词

删除

  • dw: 从当前光标开始删除到下一个单词头
  • de: 从当前光标开始删除到单词尾

收藏

收藏

1. markdown

2. url

3. Docker

  1. Docker自带的如下ARG参数,可以在其他指令中直接引用:

    • HTTP_PROXY
    • http_proxy
    • HTTPS_PROXY
    • https_proxy
    • FTP_PROXY
    • ftp_proxy
    • NO_PROXY
    • no_proxy
  2. vim 在插入模式粘贴代码缩进办法

    :set paste 粘贴完成是 set nopaste

  3. shell 自动补全忽略大小写

    add file ~/.inputrc

    set completion-ignore-case on

docker-compose

  1. 什么是Docker-Compose

Compose项目来源于之前的fig项目,使用python语言编写,与docker/swarm配合度很高。

Compose 是 Docker 容器进行编排的工具,定义和运行多容器的应用,可以一条命令启动多个容器,使用Docker Compose不再需要使用shell脚本来启动容器。

Compose 通过一个配置文件来管理多个Docker容器,在配置文件中,所有的容器通过services来定义,然后使用docker-compose脚本来启动,停止和重启应用,和应用中的服务以及所有依赖服务的容器,非常适合组合使用多个容器进行开发的场景。

docker-compose默认的模板文件是 docker-compose.yml,其中定义的每个服务都必须通过 image 指令指定镜像或 build 指令(需要 Dockerfile)来自动构建。

其它大部分指令都跟 docker run 中的类似。

如果使用 build 指令,在 Dockerfile 中设置的选项(例如:CMD, EXPOSE, VOLUME, ENV 等) 将会自动被获取,无需在 docker-compose.yml 中再次设置。
使用Compose 基本上分为三步:

1.Dockerfile 定义应用的运行环境
2.docker-compose.yml 定义组成应用的各服务
3.docker-compose up 启动整个应用

2.安装Compose

两种docker-compose安装方式

1.从github上下载docker-compose二进制文件安装

下载最新版的docker-compose文件

$ sudo curl -L https://github.com/docker/compose/releases/download/1.16.1/docker-compose-`uname -s-uname -m` -o /usr/local/bin/docker-compose
添加可执行权限
$ sudo chmod +x /usr/local/bin/docker-compose
测试安装结果

$ docker-compose –version
docker-compose version 1.16.1, build 1719ceb
2.pip安装

2.1、安装python-pip

yum -y install epel-release
yum -y install python-pip
2.2、安装docker-compose
pip install docker-compose
待安装完成后,执行查询版本的命令,即可安装docker-compose

[root@swarm01 fendo]# docker-compose version
docker-compose version 1.21.2, build a133471
docker-py version: 3.3.0
CPython version: 2.7.5
OpenSSL version: OpenSSL 1.0.2k-fips 26 Jan 2017
3.docker-compose.yml 配置文件详解

docker-compose文件结构,官方提供了一个 yaml Docker Compose 配置文件的标准例子

version: “3”
services:

redis:
image: redis:alpine
ports:
- “6379”
networks:
- frontend
deploy:
replicas: 2
update_config:
parallelism: 2
delay: 10s
restart_policy:
condition: on-failure

db:
image: postgres:9.4
volumes:
- db-data:/var/lib/postgresql/data
networks:
- backend
deploy:
placement:
constraints: [node.role == manager]

vote:
image: dockersamples/examplevotingapp_vote:before
ports:
- 5000:80
networks:
- frontend
depends_on:
- redis
deploy:
replicas: 2
update_config:
parallelism: 2
restart_policy:
condition: on-failure

result:
image: dockersamples/examplevotingapp_result:before
ports:
- 5001:80
networks:
- backend
depends_on:
- db
deploy:
replicas: 1
update_config:
parallelism: 2
delay: 10s
restart_policy:
condition: on-failure

worker:
image: dockersamples/examplevotingapp_worker
networks:
- frontend
- backend
deploy:
mode: replicated
replicas: 1
labels: [APP=VOTING]
restart_policy:
condition: on-failure
delay: 10s
max_attempts: 3
window: 120s
placement:
constraints: [node.role == manager]

visualizer:
image: dockersamples/visualizer:stable
ports:
- “8080:8080”
stop_grace_period: 1m30s
volumes:
- “/var/run/docker.sock:/var/run/docker.sock”
deploy:
placement:
constraints: [node.role == manager]

networks:
frontend:
backend:

volumes:
db-data:
一份标准配置文件应该包含 version、services、networks 三大部分,其中最关键的就是 services 和 networks 两个部分

3.1、文件配置

compose 文件是一个定义服务、 网络和卷的 YAML 文件 。Compose 文件的默认路径是 ./docker-compose.yml

服务定义包含应用于为该服务启动的每个容器的配置,就像传递命令行参数一样 docker container create。同样,网络和卷的定义类似于 docker network create 和 docker volume create。

正如 docker container create 在 Dockerfile 指定选项,如 CMD、 EXPOSE、VOLUME、ENV,在默认情况下,你不需要再次指定它们docker-compose.yml。

可以使用 Bash 类 ${VARIABLE} 语法在配置值中使用环境变量。

提示: 可以是用 .yml 或 .yaml 作为文件扩展名

3.2、版本

Compose目前为止有三个版本分别为Version 1,Version 2,Version 3,Compose区分Version 1和Version 2(Compose 1.6.0+,Docker Engine 1.10.0+)。Version 2支持更多的指令。Version 1没有声明版本默认是”version 1”。Version 1将来会被弃用。

3.3、配置选项

1.bulid

服务除了可以基于指定的镜像,还可以基于一份 Dockerfile,在使用 up 启动之时执行构建任务,这个构建标签就是 build,它可以指定 Dockerfile 所在文件夹的路径。Compose 将会利用它自动构建这个镜像,然后使用这个镜像启动服务容器
build: /path/to/build/dir
也可以是相对路径

build: ./dir
设定上下文根目录,然后以该目录为准指定 Dockerfile

build:
context: ../
dockerfile: path/of/Dockerfile

  1. context

context 选项可以是 Dockerfile 的文件路径,也可以是到链接到 git 仓库的url,当提供的值是相对路径时,它被解析为相对于撰写文件的路径,此目录也是发送到 Docker 守护进程的 context

build:
context: ./dir
3. dockerfile

使用此 dockerfile 文件来构建,必须指定构建路径
build:
context: .
dockerfile: Dockerfile-alternate
4.image

services:
web:
image: nginx
在 services 标签下的第二级标签是 web,这个名字是用户自己自定义,它就是服务名称。
image 则是指定服务的镜像名称或镜像 ID。如果镜像在本地不存在,Compose 将会尝试拉取这个镜像。
例如下面这些格式都是可以的:
image: redis
image: ubuntu:14.04
image: tutum/influxdb
image: a4bc65fd

  1. args

添加构建参数,这些参数是仅在构建过程中可访问的环境变量
首先, 在Dockerfile中指定参数:
ARG fendo
ARG password

RUN echo “Build number: $fendo”
RUN script-requiring-password.sh “$password”
然后指定 build 下的参数,可以传递映射或列表

build:
context: .
args:
fendo: 1
password: fendo

build:
context: .
args:
- fendo=1
- password=fendo
指定构建参数时可以省略该值,在这种情况下,构建时的值默认构成运行环境中的值

args:

  • fendo
  • password
    6.command

使用 command 可以覆盖容器启动后默认执行的命令。

command: bundle exec thin -p 3000
该命令也可以是一个列表,方法类似于 dockerfile:

command: [“bundle”, “exec”, “thin”, “-p”, “3000”]
7.container_name

Compose 的容器名称格式是:<项目名称><服务名称><序号>

虽然可以自定义项目名称、服务名称,但是如果你想完全控制容器的命名,可以使用这个标签指定:

container_name: app
这样容器的名字就指定为 app 了。

8.depends_on

在使用 Compose 时,最大的好处就是少打启动命令,但是一般项目容器启动的顺序是有要求的,如果直接从上到下启动容器,必然会因为容器依赖问题而启动失败。

例如在没启动数据库容器的时候启动了应用容器,这时候应用容器会因为找不到数据库而退出,为了避免这种情况我们需要加入一个标签,就是 depends_on,这个标签解决了容器的依赖、启动先后的问题。

例如下面容器会先启动 redis 和 db 两个服务,最后才启动 web 服务:

version: ‘3’
services:
web:
build: .
depends_on:
- db
- redis
redis:
image: redis
db:
image: postgres
注意的是,默认情况下使用 docker-compose up web 这样的方式启动 web 服务时,也会启动 redis 和 db 两个服务,因为在配置文件中定义了依赖关系。

9.pid

pid: “host”
将PID模式设置为主机PID模式,跟主机系统共享进程命名空间。容器使用这个标签将能够访问和操纵其他容器和宿主机的名称空间。

10.ports

映射端口的标签。

使用HOST:CONTAINER格式或者只是指定容器的端口,宿主机会随机映射端口。

ports:

  • “3000”
  • “8000:8000”
  • “49100:22”
  • “127.0.0.1:8001:8001”
    注意:当使用HOST:CONTAINER格式来映射端口时,如果你使用的容器端口小于60你可能会得到错误得结果,因为YAML将会解析xx:yy这种数字格式为60进制。所以建议采用字符串格式。
    11.extra_hosts

添加主机名的标签,就是往/etc/hosts文件中添加一些记录,与Docker client的–add-host类似:

extra_hosts:

  • “somehost:162.242.195.82”
  • “otherhost:50.31.209.229”
    启动之后查看容器内部hosts:

162.242.195.82 somehost
50.31.209.229 otherhost

12.volumes

挂载一个目录或者一个已存在的数据卷容器,可以直接使用 [HOST:CONTAINER] 这样的格式,或者使用 [HOST:CONTAINER:ro] 这样的格式,后者对于容器来说,数据卷是只读的,这样可以有效保护宿主机的文件系统。
Compose的数据卷指定路径可以是相对路径,使用 . 或者 .. 来指定相对目录。

数据卷的格式可以是下面多种形式:

volumes:
// 只是指定一个路径,Docker 会自动在创建一个数据卷(这个路径是容器内部的)。

  • /var/lib/mysql

    // 使用绝对路径挂载数据卷

  • /opt/data:/var/lib/mysql

    // 以 Compose 配置文件为中心的相对路径作为数据卷挂载到容器。

  • ./cache:/tmp/cache

    // 使用用户的相对路径(~/ 表示的目录是 /home/<用户目录>/ 或者 /root/)。

  • ~/configs:/etc/configs/:ro

    // 已经存在的命名的数据卷。

  • datavolume:/var/lib/mysql
    如果你不使用宿主机的路径,你可以指定一个volume_driver。

volume_driver: mydriver
原文:https://blog.csdn.net/u011781521/article/details/80464826
